Main page / Switches and LED indicators (Showing: 1741-1770 of 1799 elements)

Switches and LED indicators (results: 1799)

Product	Cart	Dimensions	Contacts rating	Height	Switching method	Contacts configuration	Manufacturer	Operating temperature (range)	Operating Force [gF]	Button colour	Button shape	Force	IP rating	Leads	Mounting	Type of switch	Accessories type	Backlight colour	Illumination	Key button colour	Operating voltage	Diameter	LED colours	Mechanical durability	Mounting hole diameter	Body plating	Body colour	Illimination voltage	Button marking	Cable length	Switch operation	Type of indicator	Operating current
8x8mm; height 13.5mm; Self-Lock 30V DC; 0.1A; endurance 10000 cycles; travel 1.0_0.1mm; strength 200_80gf Micros part number: PRZ Ps2215S Info Datasheet Technical drawing Add to favourites
Rys.Ps2215S			30VDC 0.1A				TACTRONIC	-5°C ~ 35°C		Blue	Square							None	None
Rys.Ps2215S	Item available on a request
KLP-5/B 230V LED blue; concave; Average hole. mounting: 10mm; 230V AC Luminosity: 40 -60 mcd; body: black; wires 300mm; IP20 Micros part number: OLB-D5-230V-AC.2 Info Datasheet Add to favourites
Rys.OLB-D5-230V-AC.2														Wires							230V	5mm	Blue			ABS material				300mm		Concave
Rys.OLB-D5-230V-AC.2	Item available on a request
KLP-5/O 230V LED orange; concave; Average hole. mounting: 10mm; 230V AC Luminosity: 12 -30 mcd; body: black; wires 300mm; IP20 Micros part number: OLO-D5-230V-AC.2 Info Datasheet Add to favourites
Rys.OLO-D5-230V-AC.2														Wires							230V	5mm	Orange			ABS material				300mm		Concave
Rys.OLO-D5-230V-AC.2	Item available on a request
XM1288-N-WS-95 TACTRONIC Switch 30V DC; 1A; 12x8,1mm; height: 9,5mm; endurance 30000 cycles; press and return force: 450gf_150gf; Micros part number: PRZ Ps1288-095 Info Datasheet Add to favourites
Rys.Ps1288-095			1A/30VDC		ON-OFF		TACTRONIC	-25°C ~ 70°C			Round
Rys.Ps1288-095	Item available on a request
KLP-10/R 12-24V LED red; concave; Average hole. mounting: 13mm; 24V AC/DC Luminosity: 800 -1200 mcd; body: black; wires 300mm; IP20 Micros part number: OLR-D10-24V-AC/DC.2 Info Datasheet Add to favourites
Rys.OLR-D10-24V-AC/DC.2														Wires							24V	10mm	Red			ABS material				300mm		Concave
Rys.OLR-D10-24V-AC/DC.2	Item available on a request
DTS-66R-V DIPTRONICS Tact switch 6.0x6.0 H=13mm, 12V DC, 50 mA, life 100000 cykli, travel 0.35mm straight, for PCB (THT), operating force 260"50gf, red color Micros part number: PRZ DTS-66R-V Info Datasheet Technical drawing Add to favourites
Rys.DTS-66R-V		6x6mm		13,0mm			DIPTRONICS		260gF						THT (Straight)
Rys.DTS-66R-V	Item available on a request
1241.1614 SCHURTER Tact switch 11.4x11.4mm H=4.55mm 12V DC, 50 mA, life 100000 cycles, travel, 0.35mm straight, for PCB (THT), operating force 180gf Micros part number: PRZ 1241.1614 Info Datasheet Add to favourites
Rys.1241.1614		11.4x11.4mm		4,55mm			SCHURTER		250gF						THT (Straight)
Rys.1241.1614	Item available on a request
KLP-10/W 12-24V LED white; concave; Average hole. mounting: 13mm; 24V AC/DC Luminosity: 1000 -3000 mcd; body: black; wires 300mm; IP20 Micros part number: OLW-D10-24V-AC/DC.2 Info Datasheet Add to favourites
Rys.OLW-D10-24V-AC/DC.2														Wires							24V	10mm	White			ABS material				300mm		Concave
Rys.OLW-D10-24V-AC/DC.2	Item available on a request
Vandal proof push button switch; W19H10R/S 19mm; momentary; 1NO; stainless steel; pin terminals; front shape-high round; 2A; 36VAC, IP65; electrical life: 200.000 cycles Micros part number: PRZ W19H10R/S Info Datasheet Technical drawing Add to favourites
Rys.W19H10R/S			2A/36VAC		1NO	N/A	N/A				Convex		IP65	For soldering		Vandal-resistant		N/A	N/A						19mm			N/A	N/A		Momentary
Rys.W19H10R/S	Item available on a request
1301.9303 SCHURTER Tact switch 6.0x6.0 H=7.0mm, 12V DC, 50 mA, life 100000 cykli, travel 0.25mm straight, for PCB (THT), operating force 160"50gf, black color Micros part number: PRZ 1301.9303 Info Datasheet Add to favourites
Rys.1301.9303		6x6mm		7,0mm			SCHURTER		160gF						THT (Straight)
Rys.1301.9303	Item available on a request
PTS645SM70SMTR92 LFS C&K Tact switch 6x6mm, H=7.0mm, 12V DC, 50mA, life 100000 cycles SMD, operating force 160gf Micros part number: PRZ PTS645SM70SMTR92 LFS Info Datasheet Add to favourites
Rys.PTS645SM70SMTR92		6x6mm		7,0mm			C&K		160gF						SMD									100000 cycles
Rys.PTS645SM70SMTR92	Item available on a request
B3FS-1050 OMRON Tact switch 5.9x9.6mm, H= 7.3mm, 24V DC, 50mA, life 1000000 cycles, travel 0.25 SMD, operating force 100gf Micros part number: PRZ B3FS-1050 Info Datasheet Add to favourites
rys.B3FS-1050		5,9x9,6mm		7,3mm			OMRON		100gF						THT (Straight)									100000 cycles
rys.B3FS-1050	Item available on a request
WP934SA/3GD LED indicators for PCBs green; 3 Single Color LEDs, Tri-Level Luminosity: 20 mcd; 40 deg; 568 nm Micros part number: OL.WP934SA/3GD Info Datasheet Technical drawing Add to favourites
Rys.OL.WP934SA/3GD																					2,2V	3mm	Green									Convex	25mA
Rys.OL.WP934SA/3GD	Item available on a request
PTS810SJG250SMTR C&K Tact switch 4.2mm x 3.2mm, wysokość 2.5mm, 12V DC, 50mA, life 100000 cycles SMD, operating force 400gf Micros part number: PRZ PTS810SJG250SMTR LFS Info Datasheet Add to favourites
Rys.PTS810SJG250SMTR		4,2x3,2mm		2,5mm			C&K		400gF						SMD									100000 cycles
Rys.PTS810SJG250SMTR	Item available on a request
431256058736 Wurth Elektronik Tact switch 12V DC, 50mA; 6x6mm; H= 5,85mm; Micros part number: PRZ 431256058736 Info Datasheet Add to favourites
Rys.431256058736		6x6mm		5,85mm			Wurth Elektronik		360gF						THT
Rys.431256058736	Item available on a request
Vandal proof push button switch; W19F11DB24/S 19mm; momentary; 1NO1NC; stainless steel; pin terminals; front shape-flat; illuminated LED 24V; dot; blue; 3A; IP67; electrical life: 40.000h Micros part number: PRZ W19F11DB24/S Info Datasheet Technical drawing Add to favourites
Rys.W19F11DB24/S					1NO1NC	N/A	N/A				Flat		IP67	For soldering		Vandal-resistant		Blue	Point						19mm			24V	N/A		Momentary
Rys.W19F11DB24/S	Item available on a request
SMBD08614 LED white; concave; mounting: 8,2mm; 24~28V DC body: silver; 2,8x0,5mm connectors; IP 67 Micros part number: OLW-D5-28V-DC Info Add to favourites
Rys.OLW-D5-28V-DC																					28V	5mm	White									Concave
Rys.OLW-D5-28V-DC	Item available on a request
ABJ151260 Panasonic Przełącznik krańcowy Micro switch; SPDT; 50mR; 2A; 125V; IP67; 1,96N; ON-(ON); temperatura pracy: -40°C~85°C Micros part number: PRZ ABJ151260 Info Datasheet Add to favourites
Rys.ABJ151260		12,8x6x5mm	2A 125V		ON-(ON)	SPDT	PANASONIC	-40°C ~ 85°C				1,96N		For PCB		Micro switch
Rys.ABJ151260	Item available on a request
ABJ151461 Panasonic Przełącznik krańcowy Micro switch; SPDT; 100mA; 125V; IP50; 0,64N; ON-(OFF); OFF-(ON); temperatura pracy: -40°C~85°C Micros part number: PRZ ABJ151461 Info Datasheet Add to favourites
Rys.ABJ151461			100mA 125V			SPDT	PANASONIC	-40°C ~ 85°C				0,64N				Micro switch
Rys.ABJ151461	Item available on a request
Vandal proof push button switch; W19F11DG24/S 19mm; momentary; 1NO1NC; stainless steel; pin terminals; front shape-flat; illuminated LED 24V; dot; green; 3A; IP67; electrical life: 40.000h Micros part number: PRZ W19F11DG24/S Info Datasheet Technical drawing Add to favourites
Rys.W19F11DG24/S					1NO1NC	N/A	N/A				Flat		IP67	For soldering		Vandal-resistant		Green	Point						19mm			24V	N/A		Momentary
Rys.W19F11DG24/S	Item available on a request
Vandal proof push button switch; W19F11DR24/S 19mm; momentary; 1NO1NC; stainless steel; pin terminals; front shape-flat; illuminated LED 24V; dot; red; 3A; IP67; electrical life: 40.000h Micros part number: PRZ W19F11DR24/S Info Datasheet Technical drawing Add to favourites
Rys.W19F11DR24/S					1NO1NC	N/A	N/A				Flat		IP67	For soldering		Vandal-resistant		Red	Point						19mm			24V	N/A		Momentary
Rys.W19F11DR24/S	Item available on a request
KLS7-TS6601-15 Tact switch 6x6mm H=15.0mm, 12V DC, 50 mA, life 100000 cycles,travel 0.30+/-0.1mm,operating temp.-20°C~70°C straight, for PCB (THT), operating force 180c50gf, return force 30gf min. Micros part number: PRZ Ts06-150 Info Datasheet Add to favourites
Rys.TS-06-150		6x6mm		15,0mm			TACTRONIC		180gF						THT (Straight)
Rys.TS-06-150	Item available on a request
DH2C-B1PA Cherry Micro switch; soldering; dimensions: 8,2x2,7x6,2mm; 0,5A; 30VDC ; ON-(ON); SPDT; endurance: 50000 cycles; 0.49N; operating temperature: -25°C+70°C Micros part number: PRZ DH2C-B1PA Info Datasheet Technical drawing Add to favourites
Rys.DH2C-B1PA		8,2x2,7x6,2mm	0.5A 30VDC		ON-(ON)	SPDT	Cherry	-25°C ~ 70°C				0,49N		For soldering		Micro switch
Rys.DH2C-B1PA	Item available on a request
Vandal proof push button switch; W19F11EB24/S 19mm; momentary; 1NO1NC; stainless steel; pin terminals; front shape-flat; illuminated LED 24V; ring; blue; 3A; IP67; electrical life: 40.000h Micros part number: PRZ W19F11EB24/S Info Datasheet Technical drawing Add to favourites
Rys.W19F11EB24/S					1NO1NC	N/A	N/A				Flat		IP67	For soldering		Vandal-resistant		Blue	Edge						19mm			24V	N/A		Momentary
Rys.W19F11EB24/S	Item available on a request
SRLS102-A2T; rocker switch; 2 stable positions; ON-ON; SPDT; 3P; 3A 125VAC or 1.5A 250VAC; endurance: 10000 cycles; ambient temperature: -20°C+85°C Micros part number: PRZ Srls102a2t Info Datasheet Technical drawing Add to favourites
Rys.SRLS102-2A2T			3A 125V 1.5A 250V		ON-ON	SPDT	N/A	-20°C ~ 85°C								Rocker	N/A			Black							Black
Rys.SRLS102-2A2T	Item available on a request
SRLS103-A2T; rocker switch; 3 stable positions; ON-OFF-ON; SPDT; 3P; 3A 125VAC or 1.5A 250VAC; endurance: 10000 cycles; ambient temperature: -20°C+85°C Micros part number: PRZ Srls103a2t Info Datasheet Technical drawing Add to favourites
Rys.SRLS103-2A2T			3A 125V 1.5A 250V		ON-OFF-ON	SPDT	N/A	-20°C ~ 85°C								Rocker	N/A			Black							Black
Rys.SRLS103-2A2T	Item available on a request
Vandal proof push button switch; W19F11ER24/S 19mm; momentary; 1NO1NC; stainless steel; pin terminals; front shape-flat; illuminated LED 24V; ring; red; 3A; IP67; electrical life: 40.000h Micros part number: PRZ W19F11ER24/S Info Datasheet Technical drawing Add to favourites
Rys.W19F11ER24/S					1NO1NC	N/A	N/A				Flat		IP67	For soldering		Vandal-resistant		Red	Edge						19mm			24V	N/A		Momentary
Rys.W19F11ER24/S	Item available on a request
914CE1-6A Honeywell Micro switch Micro switch; SPDT; 5A; 240VAC; 28VDC; 11,8N; operating temperature: 0°C+105°C Micros part number: PRZ 914CE1-6A Info Datasheet Add to favourites
Rys.914CE1-6A			5A 240VAC			SPDT	Honeywell	0°C ~ 105°C				11,8N				Micro switch
Rys.914CE1-6A	Item available on a request
D5000 HIGHLY ELECTRIC Micro switch Micro switch; SPDT; 10A; 250VAC; 25mR; 6N; M4 screws; 54,8x21,5x38,7mm; operating temperature:-25°C+70°C; endurance: 1000000 cycles Micros part number: PRZ D5000 Info Datasheet Technical drawing Add to favourites
Rys.D5000		54,8x21,5x38,7mm	10A 250VAC		ON-(ON)	SPDT	HIGHLY	-25°C ~ 70°C				6N		M4 screws		Micro switch
Rys.D5000	Item available on a request
MRS201N-3g/b; rocker switch; 2 stable positions; ON-OFF; cap colour: green; black; housing; DPST; 4P; 20A 125VAC; 16A 250VAC; endurance: 20000 cycles; ambient temperature: -25°C+85°C Micros part number: PRZ MRS201N-3g/b Info Datasheet Technical drawing Add to favourites
Rys.MRS201N-3gb			20A 125V 16A 250V		ON-OFF	DPST	N/A	-25°C ~ 85°C								Rocker	N/A			Green							Black
Rys.MRS201N-3gb	Item available on a request
